MODEL - PLG |
SPECIFICATION |
|
Length of Stroke as required |
6ft to 40ft (1800mm to 12000mm) |
|
Width between columns |
FT |
4ft |
5ft |
6ft |
7ft
to 10ft |
Width between columns |
MM |
1220 |
1524 |
1828 |
2133 to 3050 |
Height under Cross Rail |
MM |
1220 |
1524 |
1828 |
2133 |
TABLE: |
Working
Surface Length |
As per Length of stroke plus 250 mm |
|
No. of T-Slots |
MM |
5 |
5 |
6 |
7 |
Width of T-Slots |
MM |
19 |
19 |
19 |
19 |
Distance between T-Slots |
MM |
127 |
148 |
190 |
190 |
RAIL
HEADS: |
No. of Tool Holder |
One or Two as per order |
|
Horizontal
Traverse of tool holder |
MM |
900 |
1200 |
1500 |
1760 |
Vertical
Traverse of tool holder |
MM |
304 |
304 |
304 |
304 |
Max. Swivel of
tool head Slide to either side |
DEGREE |
?50? |
?50? |
?50? |
?50? |
Max. Size of
tool Shank |
MM |
44x44 |
44x44 |
50x50 |
50x50 |
Swiveling of
clapper box |
MM |
?25? |
?25? |
?25? |
?25? |
CROSS
RAIL: |
Vertical
Traverse of cross rail (elevating) |
MM |
1200 |
1500 |
1800 |
2060 |
Elevating
Traverse of head |
MM |
1080 |
1365 |
1660 |
1880 |
SPEEDS
& FEEDS: |
Single speed Forward /Return (9/13 Meters per minute
respectively) |
Table
Surface speed with 3 speed |
Gear
box at extra cost. |
FORWARD STROKE
SPEEDS |
4-7-10 |
Meters Per Minute |
|
RETURN STROKE
SPEED |
6-11-15 |
Meters Per Minute |
Cross feed of
tool head |
0.30 to 1.5 |
MM/Stroke |
|
Vertical feed of
tool head |
0.20 to 1.0 |
MM/Stroke |
|
MAIN
DRIVE |
Main Drive Motor KW 1440 RPM HP |
As per size Machine |
Cross Rail Elevating motor 960 RPM HP if Ordered at extra cost |
1 |
1.5 |
1.5 |
2.0 |
3.0 |
|
*Model PLG are without electrical. |
*We reserve the right to change design, colour or specification without notice * |
